8CH Forward Telephone
- MODEL:HHD-G8P
- G-NET HHD-G8P is 8 Channel Telephone Over Fiber Extender using the most advanced digital multiplexing communications solutions and fiber optic transmission technology,which can transmit analog and PSTN telephones or Ethernet data signals on a single fiber in real-time synchronization, no distortion, high quality. Plug and play design makes installation easy, no need for field settings and adjustment. Its optical module and the core circuit components are high quality and very stable, optical and electrical interfaces are in line with international standards and suitable for different operation environment.
G-NET HHD-G8P is 8 Channel Telephone Over Fiber Extender using the most advanced digital multiplexing communications solutions and fiber optic transmission technology,which can transmit analog and PSTN telephones or Ethernet data signals on a single fiber in real-time synchronization, no distortion, high quality. Plug and play design makes installation easy, no need for field settings and adjustment. Its optical module and the core circuit components are high quality and very stable, optical and electrical interfaces are in line with international standards and suitable for different operation environment.
The 8 POTS connection uses RJ-11C modular connectors for each copper pair connection. A pair of HHD-G8P is required to implement an end to end system.Transmitter unit connects to a telephone line (PSTN) or PBX station line and has ability to detect ringing voltages and to act as a telephone.Receiver unit is the reciprocal unit and has ability to act as PSTN and connects to a telephone device.
G-NET Telephone Over Fiber Extender Series include 1-64 channel telephone comprehensive and it is an integrated multi-channel telephone and Ethernet device. Ethernet port is a special customer requirement option, otherwise Ethernet is disabled or not included.
Features
•Full-digital uncompressed in broadcast-quality transmission
•Audio transmission compliant with ITU-T G.712,ITU-T G.714
•Support point-to-point, cascaded and distributed network connections, and SNR will not decline
•PCM Coding is adopted for Voice Coding
•Support Caller ID and Fax
•Clear voice quality, stable and reliable calls
•Multimode Fiber Support for Distances up to 2 km
•Single-Mode Fiber Support for Distances up to 100 km
•LED Status Provide Rapid Indication of Operating Parameters
•No EMI or RFI and no ground loops
•Stand alone or Wall mounted
