1CH Forward Telephone
- MODEL:HHD-G1P
G-NET HHD-G1P is 1 Channel Telephone Over Fiber Extender using the most advanced digital multiplexing communications solutions and fiber optic transmission technology, which can transmitan alog and PSTN telephones or Ethernet data signals on a single fiber inreal-time synchronization, no distortion, highquality. Plug and play design makes installation easy, no need for field settings and adjustment. It's optical module and the core circuit components are high quality and very stable, optical and electrical interfaces are inline with international standards and suit able for different operation environment.
G-NET HHD-G1P is 1Channel Telephone Over Fiber Extender using the most advanced digital multiplexing communications solutions and fiber optic transmission technology, which can transmitan alog and PSTN telephones or Ethernet data signals on a single fiber inreal-time synchronization, no distortion, highquality. Plug and play design makes installation easy, no need for field settings and adjustment. It's optical module and the core circuit components are high quality and very stable, optical and electrical interfaces are inline with international standards and suit able for different operation environment.
The 2 POTS connection uses RJ-11 Cmodular connectors for each copper pair connection. A pairof HHD-G2P isrequired to implement an end to end system. Transmitter unit connects to a telephone line(PSTN) or PBX station line and hasability to detect ringing voltages and to act as a telephone. Receiver unitis there ciprocal unit and has ability to act as PSTN and connects to a telephone device.
G-NET Telephone Over Fiber Extender Series include 1-64 channel telephone comprehensive and it is an integrated multi-channel telephone and Ethernet device.
Ethernet port is a special customer requirement option, otherwise Ethernet is disabled or not included.
•Full-digital uncompressed in broadcast-quality transmission
•Audio transmission compliant with ITU-TG.712,ITU-TG.714
•Support point-to-point, cascaded and distributed network connections, and SNR will not decline
•PCM Coding is adopted for Voice Coding
•Support Caller ID and Fax
•Clear voice quality, stable and reliable calls
•Multimode Fiber Support for Distances upto 2km
•Single-Mode Fiber Support for Distances upto 100km
•LED Status Provide Rapid Indication of Operating Parameters
•No EMI or RFI and no ground loops
•Stand alone or Wall mounted
